Model & Size 225 cu-ft Fertilizer Yes AG Lime No Litter No Organics No Seed Yes Other Granular Herbicide, low rate mico-nutrients such as sulphur and zinc. Number of products applied, including optional hopper compartments 3
Model & Size 225 cu-ft Hopper Size 225 cubic foot 3 compartment hopper 225 cu-ft, 25 cu-ft/200 cu-ft, 77 cu-ft/143 cu-ft, 109 cu-ft/116 cu-ft, 25 cu-ft/52 cu-ft/143 cu-ft and 25 cu-ft/84 cu-ft/116 cu-ft. Hopper Material 409 Stainless Steel, Painted Hopper Extensions N/A Hopper Gate Control N/A Hopper Ladder Integrated rear maintenance ladder Hopper "Inverted V" Yes Hopper Sight Window 2 Sight windows
Model & Size 225 cu-ft PTO Drive Chassis Supplied Material Distribution Booms/Spinners/Air Line ∙ 80 foot spread / 304 stainless steel booms ∙ Hydraulic boom suspension ∙ 6 foot breakaway tips – hydraulic fold ∙ Integrated controls ∙ Hydraulic independent RH and LH fold Application Swath Width, ft (m) 80 feet (24.38 m) Material Distribution Drive - Metering Drive Hydrualic driven metering Primary Metering Dual, independently driven 16 inch 304 stainless steel mesh chain conveyors (1 LH & 1 RH) Primary Metering Minimum Output Rate 56 lbs/acre* at 10 mph, 65 lbs/cu-ft Primary Metering Maximum Output Rate 1200 lbs/acre* at 10 mph, 65 lbs/cu-ft Secondary Metering Dual, independently driven 16 inch 304 stainless steel mesh chain conveyors (1 LH & 1 RH) Secondary Metering Minimum Output Rate 15 lbs/acre* at 10 mph, 65 lbs/cu-ft (Micro-Bin Standard Rate) 6 lbs/acre* at 10 mph, 65 lbs/cu-ft (Micro-Bin Low Rate) Secondary Metering Maximum Output Rate 280 lbs/acre* at 10 mph, 65 lbs/cu-ft (Micro-Bin Standard Rate) 75 lbs/acre* at 10 mph, 65 lbs/cu-ft (Micro-Bin Low Rate) Material Banding or Section Control Left/Right 2 section (manual & automatic)
Model & Size 225 cu-ft Transport wheel mounting N/A Transport tires N/A
Model & Size 225 cu-ft Hookup to tractor, mounted or pull-type Mounted - Case Trident 5550 Dry Hi Flow Jack -
Model & Size 225 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 225 cu-ft Monitors Options and Rate Control CaseIH Viper 4+ with Raven RCM Weigh System Option -
Model & Size 225 cu-ft Option 1 Electric Tarp (Optional) Option 2 LED work lights, Amber and Red tail lights Option 3 - Option 4 - Equipment Options -
