Model & Size 260 cu-ft Fertilizer Yes AG Lime No Litter No Organics No Seed Yes Other Granular Herbicide Number of products applied, including optional hopper compartments 2
Model & Size 260 cu-ft Hopper Size Dual bin: 260 cubic foot 2 compartment hopper 50/50 or 60/40 hopper split Hopper Material Standard: 409 Stainless Steel, Painted Hopper Extensions N/A Hopper Gate Control N/A Hopper Ladder ∙ Front ladder & platform ∙ 2nd hideaway maintenance ladder Hopper "Inverted V" Yes Hopper Sight Window Yes
Model & Size 260 cu-ft PTO Drive Chassis Supplied Material Distribution Booms/Spinners/Air Line ∙ 80 foot spread / 304 stainless steel ∙ Hydraulic boom suspension w/accumulator ∙ 7 foot breakaway tips – hydraulic fold ∙ Integrated controls ∙ Hydraulic independent RH and LH fold Application Swath Width, ft (m) 80 feet Material Distribution Drive 8 inch Crary fan with pwm control Metering Drive Hydrualic driven metering via chassis supplied hydraulics Primary Metering Dual, independently driven 14″ 304 stainless steel mesh chain conveyors (1 LH & 1 RH) Primary Metering Minimum Output Rate 60 lbs/acre* at 10 mph, 65 lbs/cu-ft Primary Metering Maximum Output Rate 850 lbs/acre* at 10 mph, 65 lbs/cu-ft Secondary Metering Optional: Roller Meter System for Micro-Nutrient Compartment (Single Bin only) Secondary Metering Minimum Output Rate Low Pegged Roller: 5 lbs/acre* Standard Pegged: 15 lbs/acre* Secondary Metering Maximum Output Rate Low Pegged Roller: 75 lbs/acre* Standard Pegged: 275 lbs/acre* Material Banding or Section Control Left/Right
Model & Size 260 cu-ft Transport wheel mounting - Transport tires -
Model & Size 260 cu-ft Hookup to tractor, mounted or pull-type - Jack -
Model & Size 260 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 260 cu-ft Monitors Options and Rate Control - Weigh System Option -
Model & Size 260 cu-ft Option 1 - Option 2 - Option 3 - Option 4 - Equipment Options -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 260 cu-ft Fertilizer Yes AG Lime No Litter No Organics No Seed Yes Other Granular Herbicide Number of products applied, including optional hopper compartments 2
Model & Size 260 cu-ft Hopper Size Dual bin: 260 cubic foot 2 compartment hopper 50/50 or 60/40 hopper split Hopper Material Standard: 409 Stainless Steel, Painted Hopper Extensions N/A Hopper Gate Control N/A Hopper Ladder ∙ Front ladder & platform ∙ 2nd hideaway maintenance ladder Hopper "Inverted V" Yes Hopper Sight Window Yes
Model & Size 260 cu-ft PTO Drive Chassis Supplied Material Distribution Booms/Spinners/Air Line ∙ 80 foot spread / 304 stainless steel ∙ Hydraulic boom suspension w/accumulator ∙ 7 foot breakaway tips – hydraulic fold ∙ Integrated controls ∙ Hydraulic independent RH and LH fold Application Swath Width, ft (m) 80 feet Material Distribution Drive 8 inch Crary fan with pwm control Metering Drive Hydrualic driven metering via chassis supplied hydraulics Primary Metering Dual, independently driven 14″ 304 stainless steel mesh chain conveyors (1 LH & 1 RH) Primary Metering Minimum Output Rate 60 lbs/acre* at 10 mph, 65 lbs/cu-ft Primary Metering Maximum Output Rate 850 lbs/acre* at 10 mph, 65 lbs/cu-ft Secondary Metering Optional: Roller Meter System for Micro-Nutrient Compartment (Single Bin only) Secondary Metering Minimum Output Rate Low Pegged Roller: 5 lbs/acre* Standard Pegged: 15 lbs/acre* Secondary Metering Maximum Output Rate Low Pegged Roller: 75 lbs/acre* Standard Pegged: 275 lbs/acre* Material Banding or Section Control Left/Right
Model & Size 260 cu-ft Transport wheel mounting - Transport tires -
Model & Size 260 cu-ft Hookup to tractor, mounted or pull-type - Jack -
Model & Size 260 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
