Model & Size 12 ft 14 ft 16 ft Fertilizer YES YES YES AG Lime YES YES YES Litter NO NO NO Organics NO NO NO Seed YES YES YES Other NO NO NO Number of products applied, including optional hopper compartments 1 1 1
Model & Size 12 ft 14 ft 16 ft Hopper Size 12 ft (3.66 m) Standard Profile Hopper 12 ft (3.66 m) High Profile Hopper 14 ft (4.27 m) Standard Profile Hopper 14 ft (4.27 m) High Profile Hopper 16 ft (4.27 m) Standard Profile Hopper 16 ft (4.27 m) High Profile Hopper Hopper Material Standard: 409 Stainless Steel or 304 Stainless Steel Standard: 409 Stainless Steel or 304 Stainless Steel Standard: 409 Stainless Steel or 304 Stainless Steel Hopper Extensions Standard: Hopper with No Extension Brackets Optional: Extension Brackets with 6 inch Wood Boards Standard: Hopper with No Extension Brackets Optional: Extension Brackets with 6 inch Wood Boards Standard: Hopper with No Extension Brackets Optional: Extension Brackets with 6 inch Wood Boards Hopper Gate Control - - - Hopper Ladder - - - Hopper "Inverted V" Standard: No Inverted “V” Optional: Carbon Steel Overslung Removable Inverted V Standard: No Inverted “V” Optional: Carbon Steel Overslung Removable Inverted V Standard: No Inverted “V” Optional: Carbon Steel Overslung Removable Inverted V Hopper Sight Window Laser Cut Sight Window Laser Cut Sight Window Laser Cut Sight Window
Model & Size 12 ft 14 ft 16 ft PTO Drive Powered by chassis Powered by chassis Powered by chassis Material Distribution Booms/Spinners/Air Line Stainless steel spinners, fins and spread shield Stainless steel spinners, fins and spread shield Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Material Distribution Drive Powered by chassis Powered by chassis Powered by chassis Metering Drive Hydraulic driven metering powered by chassis Hydraulic driven metering powered by chassis Hydraulic driven metering powered by chassis Primary Metering Standard: 30 inch Belt-Over-Bar Chain Optional: 20 inch Stainless Steel Mesh Chain in lieu of 30inch B-O-B Chain Standard: 30 inch Belt-Over-Bar Chain Optional: 20 inch Stainless Steel Mesh Chain in lieu of 30inch B-O-B Chain Standard: 30 inch Belt-Over-Bar Chain Optional: 20 inch Stainless Steel Mesh Chain in lieu of 30inch B-O-B Chain Primary Metering Minimum Output Rate - - - Primary Metering Maximum Output Rate - - - Secondary Metering N/A N/A N/A Secondary Metering Minimum Output Rate - - - Secondary Metering Maximum Output Rate - - - Material Banding or Section Control N/A N/A N/A
Model & Size 12 ft 14 ft 16 ft Transport wheel mounting N/A N/A N/A Transport tires N/A N/A N/A
Model & Size 12 ft 14 ft 16 ft Hookup to tractor, mounted or pull-type Truck Mounted Truck Mounted Truck Mounted Jack - - -
Model & Size 12 ft 14 ft 16 ft Required power, hp (kw) - - - Remote Hydraulic Values required N/A N/A N/A Hydraulic Pressure - - -
Model & Size 12 ft 14 ft 16 ft Monitors Options and Rate Control Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller Optional: JD Greenstar Dry ECU Controller Optional: JD Greenstar Dry Ready (37 Pin) Optional: Rate Control Ready with Spinner Monitoring Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller Optional: JD Greenstar Dry ECU Controller Optional: JD Greenstar Dry Ready (37 Pin) Optional: Rate Control Ready with Spinner Monitoring Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller Optional: JD Greenstar Dry ECU Controller Optional: JD Greenstar Dry Ready (37 Pin) Optional: Rate Control Ready with Spinner Monitoring Weigh System Option - - -
Model & Size 12 ft 14 ft 16 ft Option 1 Paint Options: Standard: Red Optional: Green, Gray or Black Accent Parts (304 SS) Paint Options: Standard: Red Optional: Green, Gray or Black Accent Parts (304 SS) Paint Options: Standard: Red Optional: Green, Gray or Black Accent Parts (304 SS) Option 2 Standard: No Trap Optional: 12 ft with Aluminum End Cups Standard: No Trap Optional: 14 ft with Aluminum End Cups Standard: No Trap Optional: 16 ft with Aluminum End Cups Option 3 - - - Option 4 - - - Equipment Options - - -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 12 ft Fertilizer YES AG Lime YES Litter NO Organics NO Seed YES Other NO Number of products applied, including optional hopper compartments 1
Model & Size 12 ft Hopper Size 12 ft (3.66 m) Standard Profile Hopper 12 ft (3.66 m) High Profile Hopper Hopper Material Standard: 409 Stainless Steel or 304 Stainless Steel Hopper Extensions Standard: Hopper with No Extension Brackets Optional: Extension Brackets with 6 inch Wood Boards Hopper Gate Control - Hopper Ladder - Hopper "Inverted V" Standard: No Inverted “V” Optional: Carbon Steel Overslung Removable Inverted V Hopper Sight Window Laser Cut Sight Window
Model & Size 12 ft PTO Drive Powered by chassis Material Distribution Booms/Spinners/Air Line Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Material Distribution Drive Powered by chassis Metering Drive Hydraulic driven metering powered by chassis Primary Metering Standard: 30 inch Belt-Over-Bar Chain Optional: 20 inch Stainless Steel Mesh Chain in lieu of 30inch B-O-B Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 12 ft Transport wheel mounting N/A Transport tires N/A
Model & Size 12 ft Hookup to tractor, mounted or pull-type Truck Mounted Jack -
Model & Size 12 ft Required power, hp (kw) - Remote Hydraulic Values required N/A Hydraulic Pressure -
