Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Fertilizer YES YES AG Lime YES NO Litter NO NO Organics NO NO Seed NO NO Other - - Number of products applied, including optional hopper compartments 1 2
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Hopper Size Single Bin: 314 cu-ft (8.89 cu-m) Single Bin: 427 cu-ft (12.09 cu-m) (includes 10 inch extensions) Multi-Bin: 377 cu-ft (10.67 cu-m) (multi-bin can be split 209/166 or 259/116) Hopper Material Standard: 409 Stainless Steel, Painted Standard: 409 Stainless Steel, Painted Hopper Extensions Standard: No Extension Brackets Standard: 10 inch Extension Brackets Hopper Gate Control Manual Operated Gate Manual Operated Gate Hopper Ladder N/A N/A Hopper "Inverted V" – – Hopper Sight Window Yes Yes
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) PTO Drive Chassis integrated hydraulics Chassis integrated hydraulics Material Distribution Booms/Spinners/Air Line Dual, independently driven 30 inch spinner disks with fertilizer and lime fins Dual, independently driven 30 inch spinner disks with fertilizer and lime fins Application Swath Width, ft (m) Lime: Up to 70 feet (21.34 m) Fertilizer: Up to 120 feet (36.58 m) Material Distribution Drive Hydraulic drive. Chassis integration Hydraulic oil cooler with integrated temperature control. Hydraulic drive. Chassis integration Hydraulic oil cooler with integrated temperature control. Metering Drive Dual, independently driven 16 inch straight belt conveyers Dual, independently driven 16 inch straight belt conveyers Primary Metering 16 inch straight belt conveyers 16 inch straight belt conveyers Primary Metering Minimum Output Rate 500 lbs/ac @ 10 mph 100 lb/cu-ft product density 35 lbs/ac @ 15mph 65 lb/cu-ft product density Primary Metering Maximum Output Rate 6000 lbs/ac @ 10 mph 100 lb/cu-ft product density 685 lbs/ac @ 15mph 65 lb/cu-ft product density Secondary Metering N/A Optional: 2 independently driven 12 inch mesh chains Secondary Metering Minimum Output Rate – 35 lbs/ac @ 15mph 65 lb/cu-ft product density Secondary Metering Maximum Output Rate – 650 lbs/ac @ 15mph 65 lb/cu-ft product density Material Banding or Section Control N/A 12 section swath control
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Transport wheel mounting Chassis integration Chassis integration Transport tires Chassis integration Chassis integration
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Hookup to tractor, mounted or pull-type Mounted: Chassis integration Mounted: Chassis Integration Jack N/A N/A
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Required power, hp (kw) - - Remote Hydraulic Values required - - Hydraulic Pressure - -
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Monitors Options and Rate Control Raven RCM Raven RCM Weigh System Option N/A N/A
Model & Size 320 cu-ft (lime) 420 cu-ft (fert) Option 1 Paint Options: Red or Green Paint Options: Red or Green Option 2 Standard: No Trap Optional: Tarp for Standard or High Profile Hoppers Stainless End Caps Standard: No Trap Optional: Tarp for Standard or High Profile Hoppers Stainless End Caps Option 3 Tail Lights - LED Red/Amber Transport: LED work lights Tail Lights - LED Red/Amber Transport: LED work lights Option 4 - - Equipment Options - -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 320 cu-ft (lime) Fertilizer YES AG Lime YES Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 320 cu-ft (lime) Hopper Size Single Bin: 314 cu-ft (8.89 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted Hopper Extensions Standard: No Extension Brackets Hopper Gate Control Manual Operated Gate Hopper Ladder N/A Hopper "Inverted V" – Hopper Sight Window Yes
Model & Size 320 cu-ft (lime) PTO Drive Chassis integrated hydraulics Material Distribution Booms/Spinners/Air Line Dual, independently driven 30 inch spinner disks with fertilizer and lime fins Application Swath Width, ft (m) Lime: Up to 70 feet (21.34 m) Material Distribution Drive Hydraulic drive. Chassis integration Hydraulic oil cooler with integrated temperature control. Metering Drive Dual, independently driven 16 inch straight belt conveyers Primary Metering 16 inch straight belt conveyers Primary Metering Minimum Output Rate 500 lbs/ac @ 10 mph 100 lb/cu-ft product density Primary Metering Maximum Output Rate 6000 lbs/ac @ 10 mph 100 lb/cu-ft product density Secondary Metering N/A Secondary Metering Minimum Output Rate – Secondary Metering Maximum Output Rate – Material Banding or Section Control N/A
Model & Size 320 cu-ft (lime) Transport wheel mounting Chassis integration Transport tires Chassis integration
Model & Size 320 cu-ft (lime) Hookup to tractor, mounted or pull-type Mounted: Chassis integration Jack N/A
Model & Size 320 cu-ft (lime) Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
