Model & Size 50 cu-ft 70 cu-ft Fertilizer NO NO AG Lime NO NO Litter NO NO Organics NO NO Seed YES YES Other - - Number of products applied, including optional hopper compartments 1 1
Model & Size 50 cu-ft 70 cu-ft Hopper Size 78.5 inches H x 74.25 inches L x 37.5 inches W *56N dimensions are for an un-mounted unit and do not include the operator platform and ladder. 80.5 inches H x 75 inches L x 49.5 inches W *56N dimensions are for an un-mounted unit and do not include the operator platform and ladder. Hopper Material Black Steel hopper Black Steel hopper Hopper Extensions - - Hopper Gate Control Manual open/close Manual open/close Hopper Ladder Ladder and platform Ladder and platform Hopper "Inverted V" - - Hopper Sight Window Sight windows near the top and bottom on each side of the hopper allow the operator to see when the bin is full and when it is nearly empty. Sight windows near the top and bottom on each side of the hopper allow the operator to see when the bin is full and when it is nearly empty.
Model & Size 50 cu-ft 70 cu-ft PTO Drive - - Material Distribution Booms/Spinners/Air Line 16 Outlets 24-Outlets Application Swath Width, ft (m) 20-30 feet** (6.10-9.14 m) **The recommended spacing is 20 inches (508 mm) between outlets, but can safely vary to match the HALO series working widths. 35-40 feet** (10.67 m – 12.19 m) **The recommended spacing is 20 inches (508 mm) between outlets, but can safely vary to match the HALO series working widths. Material Distribution Drive Hydraulic direct drive fan Hydraulic direct drive fan Metering Drive Hydrualic driven metering Hydrualic driven metering Primary Metering - - Primary Metering Minimum Output Rate - - Primary Metering Maximum Output Rate - - Secondary Metering - - Secondary Metering Minimum Output Rate - - Secondary Metering Maximum Output Rate - - Material Banding or Section Control Two section metering system – Electric Clutch Two section metering system – Electric Clutch
Model & Size 50 cu-ft 70 cu-ft Transport wheel mounting N/A N/A Transport tires - -
Model & Size 50 cu-ft 70 cu-ft Hookup to tractor, mounted or pull-type Mounted Mounted Jack - -
Model & Size 50 cu-ft 70 cu-ft Required power, hp (kw) - - Remote Hydraulic Values required - - Hydraulic Pressure - -
Model & Size 50 cu-ft 70 cu-ft Monitors Options and Rate Control ISO Control ISO Control Weigh System Option - -
Model & Size 50 cu-ft 70 cu-ft Option 1 - - Option 2 - - Option 3 - - Option 4 - - Equipment Options - -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 50 cu-ft Fertilizer NO AG Lime NO Litter NO Organics NO Seed YES Other - Number of products applied, including optional hopper compartments 1
Model & Size 50 cu-ft Hopper Size 78.5 inches H x 74.25 inches L x 37.5 inches W *56N dimensions are for an un-mounted unit and do not include the operator platform and ladder. Hopper Material Black Steel hopper Hopper Extensions - Hopper Gate Control Manual open/close Hopper Ladder Ladder and platform Hopper "Inverted V" - Hopper Sight Window Sight windows near the top and bottom on each side of the hopper allow the operator to see when the bin is full and when it is nearly empty.
Model & Size 50 cu-ft PTO Drive - Material Distribution Booms/Spinners/Air Line 16 Outlets Application Swath Width, ft (m) 20-30 feet** (6.10-9.14 m) **The recommended spacing is 20 inches (508 mm) between outlets, but can safely vary to match the HALO series working widths. Material Distribution Drive Hydraulic direct drive fan Metering Drive Hydrualic driven metering Primary Metering - Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering - Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control Two section metering system – Electric Clutch
Model & Size 50 cu-ft Transport wheel mounting N/A Transport tires -
Model & Size 50 cu-ft Hookup to tractor, mounted or pull-type Mounted Jack -
Model & Size 50 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
