Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Front row(s) ground engaging equipment (description) Smooth Low Concavity Blades or Notched Blades Smooth Low Concavity Blades or Notched Blades Smooth Low Concavity Blades or Notched Blades Smooth Low Concavity Blades or Notched Blades Smooth Low Concavity Blades or Notched Blades Front row(s) ground engaging equipment (quantity) 1 1 1 1 1 Front row(s) equipment quantity 24 30 36 42 48 Front row(s) equipment mount 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension Equipment spacing, in (mm) 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall Equipment size, in (mm) 22 in (558.8 mm) 22 in (558.8 mm) 22 in (558.8 mm) 22 in (558.8 mm) 22 in (558.8 mm) Angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle Bearings Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Rear row(s) ground engaging equipment (description) Notched Low Concavity Blades Notched Low Concavity Blades Notched Low Concavity Blades Notched Low Concavity Blades Notched Low Concavity Blades Rear row(s) ground engaging equipment (quantity) 1 1 1 1 1 Rear row(s) equipment quantity 24 30 36 42 48 Rear row(s) equipment mount 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension 4pc rubber torsion suspension Equipment spacing, in (mm) 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall 10 in (254 mm) spacing per row, 5 in (127 mm) overall Equipment size, in (mm) 22 in (558.8 m) 22 in (558.8 m) 22 in (558.8 mm) 22 in (558.8 mm) 22 in (558.8 mm) Angle 17° open angle and 4° tipped under angle 17° open angle and 4° tipped under angle 17° open angle and 4° tipped under angle 17° open angle and 4° tipped under angle 17° open angle and 4° tipped under angle Bearings Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs Multi-lip sealed, maintenance free hubs
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Transport wheel mounting 10-bolt 10-bolt 10-bolt 10-bolt 10-bolt Transport tires 600/50-22.5 Tires 600/50-22.5 Tires 600/50-22.5 Tires 600/50-22.5 Tires (800/40-22.5 with Otico Roller Option) 800/40-22.5 Tires Wing wheel mounting N/A N/A N/A N/A N/A Wing tires N/A N/A N/A N/A N/A Gauge wheel mounting N/A Mechanical gauge wheels Mechanical gauge wheels Mechanical gauge wheels Mechanical gauge wheels Guage wheel tires N/A 13.5L-15X31 Tires 500/50 R17 Tires 550/45-22.5 Tires 550/45-22.5 Tires
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Hookup to tractor, mounted or pull-type CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Typical operating depth, in (mm) 2-5 in (50.8-127 mm) 2-5 in (50.8-127 mm) 2-5 in (50.8-127 mm) 2-5 in (50.8-127 mm) 2-5 in (50.8-127 mm) Operating speed (mph) 8-14 mph (12.87-22.53 kph) 8-14 mph (12.87-22.53 kph) 8-14 mph (12.87-22.53 kph) 8-14 mph (12.87-22.53 kph) 8-14 mph (12.87-22.53 kph) Depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Fore/aft leveling Hydraulic fore/aft leveling with accumulator protection Hydraulic fore/aft leveling with accumulator protection Hydraulic fore/aft leveling with accumulator protection Hydraulic fore/aft leveling with accumulator protection Hydraulic fore/aft leveling with accumulator protection
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Required power, hp (kw) 240 - 360 hp (179.00 - 268.45 kW) 300 - 450 hp (223.71 - 335.57 kW) 360 - 540 hp (268.45 - 402.68 kW) 420 - 630 hp (313.19 - 469.79 kW) 480 - 720 hp (357.94 - 537.90 kW) Remote Hydraulic Values required 4 4 5 (includes hyd. Jack) 5 (includes hyd. Jack) 5 (includes hyd. Jack) Hydraulic Pressure - - - - -
Model & Size 20 ft 25 ft 30 ft 35 ft 40 ft Option 1 23-inch Round Bar Cage Roller Cage Roller Cage Roller Cage Roller Cage Roller Option 2 Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Option 3 Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Option 4 - - - - - Equipment Options - - - - -
Model & Size 20 ft Front row(s) ground engaging equipment (description) Smooth Low Concavity Blades or Notched Blades Front row(s) ground engaging equipment (quantity) 1 Front row(s) equipment quantity 24 Front row(s) equipment mount 4pc rubber torsion suspension Equipment spacing, in (mm) 10 in (254 mm) spacing per row, 5 in (127 mm) overall Equipment size, in (mm) 22 in (558.8 mm) Angle 14° open angle and 4° tipped under angle Bearings Multi-lip sealed, maintenance free hubs
Model & Size 20 ft Rear row(s) ground engaging equipment (description) Notched Low Concavity Blades Rear row(s) ground engaging equipment (quantity) 1 Rear row(s) equipment quantity 24 Rear row(s) equipment mount 4pc rubber torsion suspension Equipment spacing, in (mm) 10 in (254 mm) spacing per row, 5 in (127 mm) overall Equipment size, in (mm) 22 in (558.8 m) Angle 17° open angle and 4° tipped under angle Bearings Multi-lip sealed, maintenance free hubs
Model & Size 20 ft Transport wheel mounting 10-bolt Transport tires 600/50-22.5 Tires Wing wheel mounting N/A Wing tires N/A Gauge wheel mounting N/A Guage wheel tires N/A
Model & Size 20 ft Hookup to tractor, mounted or pull-type CAT 3 or CAT 4 Standard or Ball Hitch
Model & Size 20 ft Typical operating depth, in (mm) 2-5 in (50.8-127 mm) Operating speed (mph) 8-14 mph (12.87-22.53 kph) Depth control Single point depth control Fore/aft leveling Hydraulic fore/aft leveling with accumulator protection
Model & Size 20 ft Required power, hp (kw) 240 - 360 hp (179.00 - 268.45 kW) Remote Hydraulic Values required 4 Hydraulic Pressure -
Model & Size 20 ft Option 1 23-inch Round Bar Cage Roller Option 2 Otico Wave-Profile FarmFlex Rubber Roller Option 3 Double 14-inch Flat Bar Rolling Basket Option 4 - Equipment Options -
