Model & Size 60 cu-ft Fertilizer YES AG Lime NO Litter NO Organics NO Seed YES Other Granular Herbicide Number of products applied, including optional hopper compartments 1
Model & Size 60 cu-ft Hopper Size 60 cubic feet (1.69 cubic meter) Hopper Material Poly hopper Hopper Extensions N/A Hopper Gate Control Manual open/close Hopper Ladder Ladder and platform Hopper "Inverted V" Optional: Agitator kit Hopper Sight Window Poly hopper is translucent allowing the operator to see level of material inside
Model & Size 60 cu-ft PTO Drive N/A Material Distribution Booms/Spinners/Air Line Self levelling floatation booms Application Swath Width, ft (m) 60 foot spread (18.28 m) Material Distribution Drive Option: Gas engine driven fan Option: Hydrualic driven fan Metering Drive Ground driven metering and 60 speed gearbox provide 5% difference between settings Primary Metering Four section 304 Stainless steel metering system with metering rollers Standard: Four – Red, 28 groove, plastic metering rollers Optional: Four – Grey, 12 groove, metering rollers Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering - Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control Manual 4-Section control 4 Magnetic clutches and in-cab control allows 1/2 shut-off on either side
Model & Size 60 cu-ft Transport wheel mounting 14L - 16.1 implement tires / 8 ply, Rubber torsion axles Transport tires -
Model & Size 60 cu-ft Hookup to tractor, mounted or pull-type Pull-type Jack -
Model & Size 60 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 60 cu-ft Monitors Options and Rate Control ISOBUS Controls Weigh System Option -
Model & Size 60 cu-ft Option 1 Paint: Red Option 2 Weather tight lid Option 3 Tail light included Option 4 - Equipment Options -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 60 cu-ft Fertilizer YES AG Lime NO Litter NO Organics NO Seed YES Other Granular Herbicide Number of products applied, including optional hopper compartments 1
Model & Size 60 cu-ft Hopper Size 60 cubic feet (1.69 cubic meter) Hopper Material Poly hopper Hopper Extensions N/A Hopper Gate Control Manual open/close Hopper Ladder Ladder and platform Hopper "Inverted V" Optional: Agitator kit Hopper Sight Window Poly hopper is translucent allowing the operator to see level of material inside
Model & Size 60 cu-ft PTO Drive N/A Material Distribution Booms/Spinners/Air Line Self levelling floatation booms Application Swath Width, ft (m) 60 foot spread (18.28 m) Material Distribution Drive Option: Gas engine driven fan Option: Hydrualic driven fan Metering Drive Ground driven metering and 60 speed gearbox provide 5% difference between settings Primary Metering Four section 304 Stainless steel metering system with metering rollers Standard: Four – Red, 28 groove, plastic metering rollers Optional: Four – Grey, 12 groove, metering rollers Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering - Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control Manual 4-Section control 4 Magnetic clutches and in-cab control allows 1/2 shut-off on either side
Model & Size 60 cu-ft Transport wheel mounting 14L - 16.1 implement tires / 8 ply, Rubber torsion axles Transport tires -
Model & Size 60 cu-ft Hookup to tractor, mounted or pull-type Pull-type Jack -
Model & Size 60 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
