Model & Size 180 cu-ft Fertilizer YES AG Lime YES Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 180 cu-ft Hopper Size 9 feet Standard Body Hopper – 180 cu-ft (5.09 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted or 304 Stainless Steel Hopper Extensions N/A Hopper Gate Control Jack Operated Gate Hopper Ladder Standard: Hopper Ladder Hopper "Inverted V" N/A Hopper Sight Window Standard Sight Window
Model & Size 180 cu-ft PTO Drive Standard: 540 RPM Series 6 CV Joint PTO Shaft 1000 RPM Series 6 CV 1 3/4 20 Spline 1000 RPM Series 6 CV 1 3/8 21 Spline No PTO – Plug to Tractor Material Distribution Booms/Spinners/Air Line 24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 m) Fert: Up to 80 feet (24.38 m) Material Distribution Drive Standard:PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI Metering Drive #60 stainless steel ground drive chain Standard: Press Wheel Pneumatic Tire Optonal: Metal Press Wheel Primary Metering Standard: 20 inch Stainless Steel Mesh Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 180 cu-ft Transport wheel mounting 12-Ton rigid, high-clearance axle. 64"-72" reversible track width. Transport tires Standard: 11.25" x 28" Tires and Wheels Optional: 440/80R28 Tires & 15 x 28 Wheels
Model & Size 180 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: CAT 3 Cast Hitch - includes Pintle and Clevis Hitch Optional: CAT 4 Articulating Hitch Jack Heavy-duty tongue jack
Model & Size 180 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 180 cu-ft Monitors Options and Rate Control Standard: No Monitor Optional: Spinner Speed Monitor Kit Weigh System Option -
Model & Size 180 cu-ft Option 1 Paint Options: Standard: Red Optional: Green, Grey or Black Accent Parts (304 SS) Option 2 Standard: No Trap Optional: 9 foot Tarp with Aluminum End Caps Option 3 Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers and Wiring Kit Option 4 - Equipment Options -
