Model & Size 200 cu-ft, 220 cu-ft Fertilizer YES AG Lime YES Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 200 cu-ft, 220 cu-ft Hopper Size Choice: 10 ft (3.05 m) Standard Profile Hopper 200 cu-ft (5.66 cu-m) 10 ft (3.05 m) High Profile Hopper 220 cu-ft (6.23 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted or 304 Stainless Steel Hopper Extensions Standard: No Extension Brackets Optional: Extension Brackets with 6 inch boards Hopper Gate Control Jack Operated Gate Hopper Ladder Standard: Hopper with Ladder Hopper "Inverted V" Standard: No Inverted “V” Optional: 10 foot Carbon Steel Over slung Removable Inverted “V” Hopper Sight Window Standard Sight Window
Model & Size 200 cu-ft, 220 cu-ft PTO Drive Standard Options: 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD Optional: Tractor Supplied Hydraulics – Req 46 GPM total – 2300 PSI; 2 Remotes@ 23 GPM each; Zero pressure case return Material Distribution Booms/Spinners/Air Line 24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Material Distribution Drive Standard:PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI Metering Drive Standard: Tandem Gearcase Primary Metering 20 inch Stainless Steel Mesh Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 200 cu-ft, 220 cu-ft Transport wheel mounting Standard: 7 Ton Torsion Tandem Axle (12.5x15 implement tires with 6-bolt hub) Optional: 9 Ton Heavy Duty Tandem Torsion Axle (16.5x16.1 R3 tires and 8-bolt hub) or 10 Ton Walking Beam(16.5Lx16.1 R3 Tires and 8-bolt hub) Transport tires 7 Ton Torsion Tire and Wheel Options: Standard: 12.5Lx15 tires and 6-bolt wheel for 7-Ton Suspension Optional: 14Lx16.1 Flotation Tires (in lieu of Standard option) 9 Ton Torsion & 10 Ton Walking Beam Tire and Wheel Options: Standard: 16.5Lx16.1 R3 Tires and 8-bolt wheel or 16.5Lx16.1 Ribbed Implement Tires and 8-bolt wheel Optional: 21.5Lx16.1 R3 Flotation Tires (in Lieu of standard option) or 21.5Lx16.1 Ribbed Implement Flotation Tires (in Lieu of standard option) or 500/45-22.5 Tires (in Lieu of standard option)
Model & Size 200 cu-ft, 220 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: CAT 3 Cast Hitch - includes Pintle and Clevis Hitch Optional: CAT 4 Articulating Hitch Jack Heavy-duty tongue jack
Model & Size 200 cu-ft, 220 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 200 cu-ft, 220 cu-ft Monitors Options and Rate Control Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller JD Greenstar Dry ECU Controller JD Greenstar Dry Ready (37 Pin) Rate Control Ready With Spinner Monitoring Weigh System Option Standard: No Weigh System Selected for this Spreader Optional: 10 ft Tee-Jet IC-38 Integrated Weigh System 10 ft Hopper Digi-Star Weigh System – EZ2500 Indicator Digi-Star Weigh 10 ft Hopper Digi-Star Scale Link in lieu of Indicator (allows existing ISOBUS VT to function as a scale indicator)
Model & Size 200 cu-ft, 220 cu-ft Option 1 Paint Options: Standard: Red Optional: Green, Grey or Black Accent Parts (304 SS) Option 2 Standard: No Trap Optional: 10 ft Tarp with Aluminum End Caps Option 3 Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers and Wiring Kit Option 4 - Equipment Options -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 200 cu-ft, 220 cu-ft Fertilizer YES AG Lime YES Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 200 cu-ft, 220 cu-ft Hopper Size Choice: 10 ft (3.05 m) Standard Profile Hopper 200 cu-ft (5.66 cu-m) 10 ft (3.05 m) High Profile Hopper 220 cu-ft (6.23 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted or 304 Stainless Steel Hopper Extensions Standard: No Extension Brackets Optional: Extension Brackets with 6 inch boards Hopper Gate Control Jack Operated Gate Hopper Ladder Standard: Hopper with Ladder Hopper "Inverted V" Standard: No Inverted “V” Optional: 10 foot Carbon Steel Over slung Removable Inverted “V” Hopper Sight Window Standard Sight Window
Model & Size 200 cu-ft, 220 cu-ft PTO Drive Standard Options: 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD Optional: Tractor Supplied Hydraulics – Req 46 GPM total – 2300 PSI; 2 Remotes@ 23 GPM each; Zero pressure case return Material Distribution Booms/Spinners/Air Line 24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 80 feet (24.38 meters) Material Distribution Drive Standard:PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI Metering Drive Standard: Tandem Gearcase Primary Metering 20 inch Stainless Steel Mesh Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 200 cu-ft, 220 cu-ft Transport wheel mounting Standard: 7 Ton Torsion Tandem Axle (12.5x15 implement tires with 6-bolt hub) Optional: 9 Ton Heavy Duty Tandem Torsion Axle (16.5x16.1 R3 tires and 8-bolt hub) or 10 Ton Walking Beam(16.5Lx16.1 R3 Tires and 8-bolt hub) Transport tires 7 Ton Torsion Tire and Wheel Options: Standard: 12.5Lx15 tires and 6-bolt wheel for 7-Ton Suspension Optional: 14Lx16.1 Flotation Tires (in lieu of Standard option) 9 Ton Torsion & 10 Ton Walking Beam Tire and Wheel Options: Standard: 16.5Lx16.1 R3 Tires and 8-bolt wheel or 16.5Lx16.1 Ribbed Implement Tires and 8-bolt wheel Optional: 21.5Lx16.1 R3 Flotation Tires (in Lieu of standard option) or 21.5Lx16.1 Ribbed Implement Flotation Tires (in Lieu of standard option) or 500/45-22.5 Tires (in Lieu of standard option)
Model & Size 200 cu-ft, 220 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: CAT 3 Cast Hitch - includes Pintle and Clevis Hitch Optional: CAT 4 Articulating Hitch Jack Heavy-duty tongue jack
Model & Size 200 cu-ft, 220 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
