Model & Size 264 cu-ft 440 cu-ft Fertilizer YES YES AG Lime YES YES Litter NO NO Organics NO NO Seed NO NO Other - - Number of products applied, including optional hopper compartments 1 1
Model & Size 264 cu-ft 440 cu-ft Hopper Size 12 ft High Profile Hopper 264 cu-ft (7.48 cu-m) 20 ft 96 in Wide Hopper 440 cu-ft (12.46 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted Optional: 304 Stainless Steel Standard: 409 Stainless Steel, Painted Optional: 304 Stainless Steel Hopper Extensions Standard: No Extension Brackets Standard: No Extension Brackets Optional: 6 inch extension brackets Optional: Extension Brackets for 6 inch boards Hopper Gate Control Jack Operated Gate Jack Operated Gate Hopper Ladder - Ladder included Hopper "Inverted V" Standard: Removeable Over-Slung V * The Over-Slung V running along the length of the hopper help prevent material from bridging in the hopper. Standard: Removeable Over-Slung V * The Over-Slung V running along the length of the hopper help prevents overloading of the belt. Hopper Sight Window Standard Sight Window Standard Sight Window
Model & Size 264 cu-ft 440 cu-ft PTO Drive Choice: 1000 RPM Series 6 CV 1 3/4 20 Spline Choice: 1000 RPM Series 6 CV 1 3/8 21 Spline Choice: Tractor Supplied Hydraulics for MagnaSpread* *Requires 50 GPM total with max pressure of 2800 PSI. 2 Remotes, 1 at 30 GPM with a 3rd line case drain for Spinners and 1 at 20 GPM for the Conveyor. This hydraulic configuration (does not) include an oil cooler and one cannot be added. Use of 1/2″ coupler on spinner circuit will likely result in reduced performance in heavy applications such as lime. Choice: 1000 RPM Series 6 CV 1 3/4 20 Spline Choice: 1000 RPM Series 6 CV 1 3/8 21 Spline Choice: Tractor Supplied Hydraulics for MagnaSpread* *Requires 50 GPM total with max pressure of 2800 PSI. 2 Remotes, 1 at 30 GPM with a 3rd line case drain for Spinners and 1 at 20 GPM for the Conveyor. This hydraulic configuration (does not) include an oil cooler and one cannot be added. Use of 1/2″ coupler on spinner circuit will likely result in reduced performance in heavy applications such as lime. Material Distribution Booms/Spinners/Air Line 30 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield 30 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 120 feet (36.58 meters) Lime: Up to 60 feet (18.29 meters) Fert: Up to 120 feet (36.58 meters) Material Distribution Drive Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics Metering Drive Tandem conveyor drive gearbox Tandem conveyor drive gearbox Primary Metering Standard: 30 inch Belt-Over-Bar Chain Standard: 30 inch Belt-Over-Bar Chain Primary Metering Minimum Output Rate - - Primary Metering Maximum Output Rate - - Secondary Metering N/A N/A Secondary Metering Minimum Output Rate - - Secondary Metering Maximum Output Rate - - Material Banding or Section Control N/A N/A
Model & Size 264 cu-ft 440 cu-ft Transport wheel mounting Standard: 90 inch to 120 inch adjustable axle | Optional: 120 inch to 152 inch adjustable axle Heavy Duty 20 Ton Walking Beam Undercarriage Transport tires Standard: 380/90R46 tires | Optional: 800/65R32 (only available with 90 to 120 axle) 800/65R32
Model & Size 264 cu-ft 440 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: Cast Hitch for pull-type Spreaders - Includes Pintle and Clevis Hitch. Optional: Articulating Hitch Pull-type - Standard: Cast Hitch for pull-type Spreaders - Includes Pintle and Clevis Hitch. or Articulating Hitch Jack Heavy-duty tongue jack Heavy-duty tongue jack
Model & Size 264 cu-ft 440 cu-ft Required power, hp (kw) - - Remote Hydraulic Values required - - Hydraulic Pressure - -
Model & Size 264 cu-ft 440 cu-ft Monitors Options and Rate Control Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller Optional: JD Greenstar Dry ECU Controller Optional: JD Greenstar Dry Ready (37 Pin) Optional: Rate Control Ready with Spinner Monitoring Standard: No Controller Optional: Tee-Jet IC-38 ISOBUS Controller Optional: JD Greenstar Dry ECU Controller Optional: JD Greenstar Dry Ready (37 Pin) Optional: Rate Control Ready with Spinner Monitoring Weigh System Option Standard: No Scales or Weigh System Optional: Tee-Jet IC-38 Integrated Weigh System Optional: Digi-Star Indicator Weigh System – EZ2500 indicator Optional: Digi-Star Scale Link Weigh System Standard: No Scales or Weigh System Optional: Tee-Jet IC-38 Integrated Weigh System Optional: Digi-Star Indicator Weigh System – EZ2500 indicator Optional: Digi-Star Scale Link Weigh System
Model & Size 264 cu-ft 440 cu-ft Option 1 Paint Options: Standard: Red Optional: Green, Grey or Black Accent Parts (304 SS) Paint Options: Standard: Red Optional: Green, Grey or Black Accent Parts (304 SS) Option 2 Standard: No Trap Optional: Tarp for Standard or High Profile Hoppers Stainless End Caps Standard: No Trap Optional: Tarp for Standard or High Profile Hoppers Stainless End Caps Option 3 Standard: Rear Tail lights with turn signal, Side markers Standard: Rear Tail lights with turn signal, Side markers Option 4 - - Equipment Options - -
Select 246 Applicator[*]60 cu-ft 4056 Applicator[*]40 cu-ft 5500 Applicator[*]167 cu-ft 56N Series Mounted Cover Crop Seeder[*]50 cu-ft 56N Series Mounted Cover Crop Seeder[*]70 cu-ft 6056 Applicator[*]60 cu-ft 8600 Applicator[*]260 cu-ft 8600 Applicator[*]357 cu-ft 8700 Applicator[*]260 cu-ft 8700 Applicator[*]357 cu-ft 9620 Air Boom Applicator[*]Standard: 660 cu-ft AB200DS2 Applicator for John Deere[*]200 cu-ft AB200DSM Applicator for John Deere[*]215 cu-ft AB230CD Applicator for CaseIH Trident[*]225 cu-ft AB260CS Applicator for CaseIH Trident[*]260 cu-ft AB300AF Applicator for AGCO Floaters[*]300 cu-ft single product AB300AF Applicator for AGCO Floaters[*]300 cu-ft dual product AB320AF Applicator for AGCO Floaters[*]320 cu-ft single product hopper AB320AF Applicator for AGCO Floaters[*]320 cu-ft dual product hopper AB320DF Applicator for John Deere[*]320 cu-ft AB640 Applicator[*]Standard: 640 cu-ft BBI Endurance Spreader[*]304 cu-ft , 400 cu-ft BBI Endurance Spreader[*]342 cu-ft, 450 cu-ft BBI Endurance Spreader[*]380 cu-ft, 500 cu-ft BBI Endurance Spreader[*]456 cu-ft, 550 cu-ft BBI Endurance Truck Mount[*]16 ft - 320 cu-ft BBI Endurance Truck Mount[*]18 ft - 360 cu-ft BBI Endurance Truck Mount[*]20 ft - 400 cu-ft BBI Endurance Truck Mount[*]24 ft - 480 cu-ft Cricket Vineyard Spinner Spreader[*]63.5 cu-ft Ferti-GO Applicator[*]120 cu-ft, 180 cu-ft Grasshopper HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Grasshopper Spinner Spreader[*]180 cu-ft Liberty HDR Spinner Spreader[*]200 cu-ft, 220 cu-ft Liberty Spinner Spreader[*]200 cu-ft or 220 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]264 cu-ft MagnaSpread PLUS+ Spinner Spreader[*]440 cu-ft MagnaSpread Spinner Spreader[*]320 cu-ft, 352 cu-ft MagnaSpread Truck Mount Spinner Spreader[*]12 ft MagnaSpread Truck Mount Spinner Spreader[*]14 ft MagnaSpread Truck Mount Spinner Spreader[*]16 ft Sniper Spinner Spreader[*]264 cu-ft SS400+ Chassis Mounted[*]320 cu-ft (lime) SS400+ Chassis Mounted[*]420 cu-ft (fert) ST-Series Applicators[*]120 cu-ft ST-Series Applicators[*]180 cu-ft ST-Series Applicators[*]300 cu-ft ST-Series Applicators[*]360 cu-ft Trooper Spinner Spreader[*]270 cu-ft
Model & Size 264 cu-ft Fertilizer YES AG Lime YES Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 264 cu-ft Hopper Size 12 ft High Profile Hopper 264 cu-ft (7.48 cu-m) Hopper Material Standard: 409 Stainless Steel, Painted Optional: 304 Stainless Steel Hopper Extensions Standard: No Extension Brackets Hopper Gate Control Jack Operated Gate Hopper Ladder - Hopper "Inverted V" Standard: Removeable Over-Slung V * The Over-Slung V running along the length of the hopper help prevent material from bridging in the hopper. Hopper Sight Window Standard Sight Window
Model & Size 264 cu-ft PTO Drive Choice: 1000 RPM Series 6 CV 1 3/4 20 Spline Choice: 1000 RPM Series 6 CV 1 3/8 21 Spline Choice: Tractor Supplied Hydraulics for MagnaSpread* *Requires 50 GPM total with max pressure of 2800 PSI. 2 Remotes, 1 at 30 GPM with a 3rd line case drain for Spinners and 1 at 20 GPM for the Conveyor. This hydraulic configuration (does not) include an oil cooler and one cannot be added. Use of 1/2″ coupler on spinner circuit will likely result in reduced performance in heavy applications such as lime. Material Distribution Booms/Spinners/Air Line 30 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Lime: Up to 60 feet (18.29 meters) Fert: Up to 120 feet (36.58 meters) Material Distribution Drive Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics Metering Drive Tandem conveyor drive gearbox Primary Metering Standard: 30 inch Belt-Over-Bar Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 264 cu-ft Transport wheel mounting Standard: 90 inch to 120 inch adjustable axle | Optional: 120 inch to 152 inch adjustable axle Transport tires Standard: 380/90R46 tires | Optional: 800/65R32 (only available with 90 to 120 axle)
Model & Size 264 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: Cast Hitch for pull-type Spreaders - Includes Pintle and Clevis Hitch. Optional: Articulating Hitch Jack Heavy-duty tongue jack
Model & Size 264 cu-ft Required power, hp (kw) - Remote Hydraulic Values required - Hydraulic Pressure -
