Model & Size 270 cu-ft Fertilizer YES AG Lime NO Litter NO Organics NO Seed NO Other - Number of products applied, including optional hopper compartments 1
Model & Size 270 cu-ft Hopper Size 10 foot Hopper 270 cu-ft (7.64 cu-m) Hopper Material 409 Stainless Steel, Painted Hopper Extensions N/A Hopper Gate Control Jack Operated Gate Hopper Ladder Standard: Hopper Ladder Hopper "Inverted V" Standard Hopper Sight Window Standard Sight Window
Model & Size 270 cu-ft PTO Drive Choice: 540 RPM Series 6 CV Joint PTO Shaft 1000 RPM Series 6 CV 1 3/4 20 Spline 1000 RPM Series 6 CV 1 3/8 21 Spline No PTO – Plug to Tractor Hydraulic spinner Material Distribution Booms/Spinners/Air Line 24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield Application Swath Width, ft (m) Fert: Up to 80 feet (24.38 m) Material Distribution Drive Standard: PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI Metering Drive #60 stainless steel ground drive chain Standard: Press Wheel Pneumatic Tire Optonal: Metal Press Wheel Primary Metering 8 inch Stainless Steel Mesh Chain Primary Metering Minimum Output Rate - Primary Metering Maximum Output Rate - Secondary Metering N/A Secondary Metering Minimum Output Rate - Secondary Metering Maximum Output Rate - Material Banding or Section Control N/A
Model & Size 270 cu-ft Transport wheel mounting 10,000 lbs Torsion axles Transport tires 21.5Lx16.1 Flotation tires, 8 bolt hubs
Model & Size 270 cu-ft Hookup to tractor, mounted or pull-type Pull-type - Standard: CAT 3 Cast Hitch - includes Pintie and Clevis Hitch Jack Heavy-duty tongue jack
Model & Size 270 cu-ft Required power, hp (kw) - Remote Hydraulic Values required One set for ground wheel engagement. If Hydraulic spinners 2, One for ground wheel engagement, one to operate the spinners. Hydraulic Pressure Hydraulic Spinner option: 21 GPM @ 2000psi
Model & Size 270 cu-ft Monitors Options and Rate Control Spinner Speed Monitor Option Weigh System Option N/A
Model & Size 270 cu-ft Option 1 Paint Options: Standard: Red Optional: Green or Grey Option 2 Standard: No Trap Optional: 10 foot Tarp with Aluminum End Caps Option 3 Standard: Rear Tail Lights with Turn Signal, Side Markers Option 4 - Equipment Options -
