Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Front row(s) ground engaging equipment (description) Tine roller Tine roller Tine roller Tine roller Tine roller Tine roller Tine roller Tine roller Front row(s) ground engaging equipment (quantity) 1 1 1 1 1 1 1 1 Front row(s) equipment quantity Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Front row(s) equipment mount Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Tines bolt on to roller Equipment spacing, in (mm) Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Equipment size, in (mm) Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Angle 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option 0, 2.5, 5 degrees, adjustment depends on tine option Bearings - - - - - - - -
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Rear row(s) ground engaging equipment (description) - - - - - - - - Rear row(s) ground engaging equipment (quantity) - - - - - - - - Rear row(s) equipment quantity - - - - - - - - Rear row(s) equipment mount - - - - - - - - Equipment spacing, in (mm) - - - - - - - - Equipment size, in (mm) - - - - - - - - Angle - - - - - - - - Bearings - - - - - - - -
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Transport wheel mounting - - - - - - - - Transport tires - - - - - - - - Wing wheel mounting - - - - - - - - Wing tires - - - - - - - - Gauge wheel mounting - - - - - - - - Guage wheel tires - - - - - - - -
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Hookup to tractor, mounted or pull-type 3 point mount 3 point mount 3 point mount 3 point mount Hydraulic Wheel Kit Hydraulic Wheel Kit Hydraulic Wheel Kit Hydraulic Wheel Kit
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Typical operating depth, in (mm) Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Varies by tine option Operating speed (mph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) 7-10 mph (11.27–16.09 kph) Depth control - - - - - - - - Fore/aft leveling - - - - - - - -
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Required power, hp (kw) 56.25 - 82.5 hp (41.95 - 61.52 kW) 100 - 150 hp (74.57 - 111.86 kW) 156.25 - 218.75 hp (116.54 - 163.24 kW) 225 - 300 hp (167.78 - 223.71 kW) 67.5 - 93.75 hp (50.31 - 69.92 kW) 125 - 175 hp (93.21 - 130.50 kW) 187.50 - 250 hp (139.82 - 186.43 kW) 262.5 - 375 hp (195.79 - 279.64 kW) Remote Hydraulic Values required - - - - - - - - Hydraulic Pressure - - - - - - - -
Model & Size 45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type Option 1 Choice of tine Choice of tine Choice of tine Choice of tine Choice of tine Choice of tine Choice of tine Choice of tine Option 2 Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Greens Express Smoothing Roller Kit Option 3 Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Steel Plate Ballast Option 4 - - - - - - - - Equipment Options - - - - - - - -
45 in. 3 Point 60 in. 3 Point 75 in. 3 Point 90 in. 3 Point 45 in. Hydraulic Pull-type 60 in. Hydraulic Pull-type 75 in. Hydraulic Pull-type 90 in. Hydraulic Pull-type
Model & Size 45 in. 3 Point Front row(s) ground engaging equipment (description) Tine roller Front row(s) ground engaging equipment (quantity) 1 Front row(s) equipment quantity Varies by tine option Front row(s) equipment mount Tines bolt on to roller Equipment spacing, in (mm) Varies by tine option Equipment size, in (mm) Varies by tine option Angle 0, 2.5, 5 degrees, adjustment depends on tine option Bearings -
Model & Size 45 in. 3 Point Rear row(s) ground engaging equipment (description) - Rear row(s) ground engaging equipment (quantity) - Rear row(s) equipment quantity - Rear row(s) equipment mount - Equipment spacing, in (mm) - Equipment size, in (mm) - Angle - Bearings -
Model & Size 45 in. 3 Point Transport wheel mounting - Transport tires - Wing wheel mounting - Wing tires - Gauge wheel mounting - Guage wheel tires -
Model & Size 45 in. 3 Point Hookup to tractor, mounted or pull-type 3 point mount
Model & Size 45 in. 3 Point Typical operating depth, in (mm) Varies by tine option Operating speed (mph) 7-10 mph (11.27–16.09 kph) Depth control - Fore/aft leveling -
Model & Size 45 in. 3 Point Required power, hp (kw) 56.25 - 82.5 hp (41.95 - 61.52 kW) Remote Hydraulic Values required - Hydraulic Pressure -
Model & Size 45 in. 3 Point Option 1 Choice of tine Option 2 Greens Express Smoothing Roller Kit Option 3 Steel Plate Ballast Option 4 - Equipment Options -
